Industrial Bag Type Dust Remover
Pulse Bag Dust Collector Introduction：
Industrial Bag Type Dust Remover This pulse bag-type dust remover is an industrial dry dust purification equipment, widely used to capture granular smoke, powder dust generated during factory production.
Industrial Bag Type Dust Remover The whole machine adopts thick carbon steel plate welding structure, with solid frame, stable operation and long service life.The equipment is composed of air inlet box, filter bag chamber, pulse jet cleaning system, ash hopper, ash discharge valve and induced draft fan matching interface.
Industrial Bag Type Dust Remover Inside the box, high-density filter bags are installed as the core filtering medium, which can block fine solid dust particles from exhaust gas. Equipped with automatic pulse blowback cleaning device, compressed air regularly sprays to shake off dust accumulated on the surface of filter bags, maintaining continuous stable dust removal efficiency.Customizable number of filter bags and air processing volume to match different dust concentration working conditions.
Industrial Bag Type Dust Remover It can capture fine dust above 0.1μm, dust removal efficiency reaches over 99%, effectively solving workshop dust pollution, improving working environment and helping factories meet environmental protection emission standards.
Core Advantages：
1.High dust removal efficiency, capture ultra-fine industrial powder, filtration efficiency ≥99%
2.Automatic pulse self-cleaning system, no frequent manual cleaning, continuous 24h operation
3.Thickened steel welded body, wear-resistant and pressure-resistant, suitable for harsh factory environments
4.Modular design, easy to replace filter bags, convenient daily maintenance
5.Low operating noise, small air resistance, save fan power consumption
6.Wide compatibility for various dry dust: metal grinding dust, wood powder, mineral powder, plastic dust, cement dust etc.
Dust collector working principle
Working Principle of Pulse Bag Dust Collector
1.Dust Filtration Stage
Dust-laden flue gas enters the equipment from the side air inlet, and flows into the filter bag chamber. When dusty gas passes through the surface of the fabric filter bag, solid dust particles are blocked and adhered to the outer surface of the filter bag, while clean air penetrates the filter bag and flows into the upper air outlet box, then discharged out of the equipment through the fan up to standard. Dust accumulates layer by layer on the outer wall of filter bags as continuous working.
2.Industrial Bag Type Dust Remover Automatic Pulse Ash Cleaning Stage
When the dust thickness on filter bags reaches the set resistance value, the pulse control system automatically opens the electromagnetic pulse valve. High-pressure compressed air instantly sprays into each filter bag from the top blowpipe, forming instantaneous shock wave inside the bag. The filter bag rapidly expands and vibrates violently, shaking off the dust attached on the outer surface. The fallen dust slides down into the bottom ash hopper, and can be regularly cleared by ash discharge valve. Filtration and ash cleaning run alternately without shutdown, realizing uninterrupted long-term dust collection.
Application scenarios
1. Metal Processing & Hardware Grinding WorkshopGrinding, polishing, cutting, sandblasting, laser cutting, metal forging production lines. Collect iron powder, aluminum dust, steel oxide smoke generated during metal machining.
2. Woodworking & Furniture Manufacturing FactoryWood cutting, sanding, engraving, paint polishing processes. Remove wood flour, wood shavings and fine wood dust to avoid workshop dust explosion risks.
3. Building Materials & Cement IndustryCement plant, stone cutting workshop, lime processing, ceramic tile polishing, sand making factory. Capture stone powder, cement dust, mineral particulate pollutants.
4. Chemical & Plastic Processing PlantPlastic crushing, mixing, granulation, rubber vulcanization workshop. Filter plastic powder, chemical raw material dust, pigment powder.
5. Mining & Metallurgy FactoryOre crushing, screening, smelting flue gas pretreatment, mineral powder transportation lines. Deal with ore dust, metallurgical smoke and heavy metal particles.
6. Food & Feed Processing FactoryGrain milling, feed mixing, flour processing, spice grinding workshops. Collect flour dust, grain powder, feed raw material dust, meet food hygiene standards.
7. Foundry WorkshopSand casting, casting polishing, sand treatment production line. Separate casting sand dust, casting smoke and metal ash.
8. Industrial Bag Type Dust Remover Waste Recycling IndustryMetal scrap crushing, plastic recycling, waste battery dismantling workshop. Recycle recyclable powder and control flying dust pollution.
9. Pharmaceutical Raw Material FactoryMedicine crushing, powder mixing, tablet pressing workshop. Capture medicinal fine powder to keep workshop clean and avoid raw material waste.
10. Industrial Bag Type Dust Remover Other Applicable ScenariosConcrete mixing station, asphalt plant, boiler flue gas dedusting, textile fiber processing, battery manufacturing workshop.
